TDZ5-WS bench top PRP used laboratory centrifuge
Features:
Enhanced ergonomics to achieve a streamline design that is safe,aesthetic and practical.
With TFT true-color LCD wide-screen touch monitor featured by intelligent control,easy and convenient operation,a touch panel and a simultaneous indication of both the set parameters and operation ones.
With a complete steel structure and a stainless steel centrifuge cavity,it is sturdy and durable.
Variable-frequency brushless motor that is maintenance and dust-free.
10 kinds of speed-up and speed-down options.Can store 20 user program which can be directly used by the user.The program previously used with be running when the machine is started.
TDZ5-WS bench top PRP used laboratory centrifuge With a dedicated key indicating the centrifugal force.
With a motor gate lock mute mechanical & electrical integration.
Multiple layers of shock absorbers with the function of automatic balancing to achieve smooth operation.
|
specifications:
|
|
Model
|
TDZ5-WS
|
|
Max capacity
|
4×100 ml
|
|
Max speed（r/min）
|
5000
|
|
Max RCF（×g）
|
3580
|
|
Speed precision
|
±50r/min
|
|
Time range
|
0-99h59min
|
|
Operation programe
|
20
|
|
Control and drive system
|
Frequency motor，micro control，direct drive
|
|
Total power
|
350 W
|
|
Power
|
AC220V 50Hz
|
|
Noise
|
≤65 dB
|
|
dimension（L×W×H）
|
500×450×280 mm
|
|
Weight
|
25 Kg
|
|
